Description
Vehicle Compatibility
- Toyota Camry 220Si 2.2 5S FE 1997 to 2000
- Toyota Camry 220S 2.2 5S FE 1997 to 2000
- For 1997 and later models within this year range using the 5S FE engine
Specifications
- Part type: Cylinder head stretch bolt set
- Set contents: Pack of 10 bolts
- Thread size: M10
- Bolt head design: Male star drive
- Overall length: 95 mm
- Engine code: 5S FE
- Vehicle: Toyota Camry 220Si and 220S 2.2 petrol
- Model years: 1997 to 2000 only
- Designed as torque to yield cylinder head bolts
- To be used together with the correct MLS head gasket set such as CHK00103
Features
- Stretch bolt design helps maintain consistent clamping force on the 5S FE cylinder head.
- M10 thread and 95 mm length matched to Toyota Camry 220Si and 220S 2.2 engines.
- Male star head allows accurate torque and angle tightening with the correct tooling.
- Supplied as a full pack of 10 bolts for a complete cylinder head refit.
- Ideal to pair with an MLS head gasket set for long term sealing on rebuilt engines.
- Suitable for daily use and highway driving in typical South African conditions.
Why Buy From Us
- Local stock of cylinder head bolt sets for popular Toyota 5S FE engines.
- 12 month warranty against manufacturing defects when installed by a qualified workshop.
- Fitment support available to confirm 81013500 with your Camry and matching gasket set CHK00103.
- Fast nationwide delivery to Johannesburg, Pretoria, Durban, Cape Town, Gqeberha, Bloemfontein and more.
- Trusted by South African workshops and engine rebuilders for reliable engine hardware.
Installation & Maintenance Tips
- Always use a complete new set of stretch bolts when refitting the cylinder head on a 5S FE engine.
- Follow the factory specified torque and angle sequence exactly, using a calibrated torque wrench and angle gauge.
- Lightly oil the bolt threads and under head seating area if recommended by the service information.
- Ensure block and head surfaces are clean, flat and correctly prepared before tightening the bolts.
- Never reuse old stretch bolts, as they can lose clamping force and lead to head gasket failure.
- After assembly, monitor coolant level, engine temperature and oil condition during the initial running in period.
Engine Parts Installation Warning
This cylinder head bolt set is an internal engine fastener kit and must be installed by a suitably qualified technician using the correct tools and service data. Incorrect tightening sequence, torque or re use of bolts can cause serious engine damage or repeated head gasket failure.
- Follow the official service procedure for the Toyota 5S FE engine when tightening these bolts.
- Confirm the correct torque and angle stages and apply them in the specified order.
- Do not reuse removed stretch bolts; always fit a complete new set such as 81013500.
- Verify coolant type, oil grade and service intervals after the engine rebuild is complete.
Engine Parts Return Policy Warning
Internal engine fasteners such as cylinder head bolt sets are sensitive safety related parts. Once opened or trial fitted they generally cannot be resold safely. Returns of 81013500 are only possible if the incorrect part was supplied and it remains unused, clean and fully sealed in the original packaging.
- Check the engine code 5S FE and vehicle details before opening the bolt set.
- Do not mark, clamp or install any bolt if you are unsure it is correct, as this will classify it as used.
- All returned items must be inspected to confirm they are unused, undamaged and complete.
- Opened, contaminated or fitted bolts are non returnable except where required by law for proven manufacturing defects.
