Concentric Slave Cylinder Luk Ford Ranger Transit & Mazda BT-50 – 510 0235 12

SKU: 510 0235 12
(0)
LUK
R 2,576.69
R 2,576.69
R 0
Sold out
Quantity must be 1 or more

Fast & Secure Checkout

    Description

    Vehicle Fitment & Part Details

    Luk concentric slave cylinder for the Ford Ranger (TKE) 2.2/3.2 TDCi (2011–), Ford Transit 2.4/3.2 TDCi (2004–2014), Land Rover Defender (L316), and Mazda BT-50 2.2 MZ-CD (2012–), cross-referencing OE 4C117C559AH. The concentric slave cylinder is a hydraulic clutch release bearing mounted inside the bell housing that actuates the clutch when the pedal is pressed. Confirm compatibility by matching the listed fitment details, any OEM reference numbers supplied, and VIN/engine/chassis information where variants exist.

    Key Details

    SKU
    510 0235 12
    Component
    Concentric Slave Cylinder
    Brand
    LUK
    Primary Fitment
    Ford Ranger (TKE) 2.2/3.2 TDCi (2011–)

    Key Benefits

    • Cross-references 20 Ford OEM part numbers including 4C117C559AH, JB3R7A564AA, and JB3R7A564AB — verify against your original part before ordering.
    • LUK-branded concentric slave cylinder — LUK is a recognised OE supplier of clutch hydraulic components.

    OEM Reference Numbers

    • Ford: 4C117C559AA, 4C117C559AB, 4C117C559AC, 4C117C559AD, 4C117C559AE, 4C117C559AF, 4C117C559AG, 4C117C559AH
    • Ford: JB3R7A564AA, JB3R7A564AB
    • Ford: 1468026, 1512917, 1675978, 1732558, 1775485, 1824839, 2019956, 2214499, 2617327, 4543504

    Vehicle Fitment

    Includes 33 supplied applications.

    Make Model Engine Power Years
    Ford Ranger (TKE) 2.2 TDCi ENQW; GBVAJQW 92 kW / 125 PS 2011–
    Ford Ranger (TKE) 4x4 2.2 TDCi ENQW; GBVAJQW 92 kW / 125 PS 2011–
    Ford Ranger (TKE) 4x4 2.2 TDCi GBVAJQJ; ENQJ 110 kW / 150 PS 2011–
    Ford Ranger (TKE) 2.2 TDCi ENPF; GBVAJPF 88 kW / 120 PS 2011–
    Ford Ranger (TKE) 2.2 TDCi GBVAJQJ; ENQJ 110 kW / 150 PS 2011–
    Ford Ranger (TKE) 2.2 TDCi GBVAJQJ; T22DD0P 118 kW / 160 PS 2015–
    Ford Ranger (TKE) 4x4 2.2 TDCi GBVAJQJ; T22DD0P 118 kW / 160 PS 2015–
    Ford Ranger (TKE) 2.2 TDCi T22DD0P 96 kW / 131 PS 2015–
    Ford Ranger (TKE) 4x4 2.2 TDCi T22DD0P 96 kW / 131 PS 2015–
    Ford Ranger (TKE) 4x4 3.2 TDCi SA2S; SA2W; ENSA; SAFA; P5-AT; SA2R 147 kW / 200 PS 2011–
    Ford Ranger (TKE) 4x4 2.0 EcoBlue YN2X; T20DD0J 157 kW / 213 PS 2018–
    Ford Ranger (TKE) 4x4 2.0 EcoBlue T20DD0J 96 kW / 131 PS 2019–
    Ford Ranger (TKE) 4x4 2.0 EcoBlue T20DD0J; BC2X 125 kW / 170 PS 2019–
    Ford Transit Bus 2.4 TDCi H9FA 101 kW / 137 PS 2004–2006
    Ford Transit Bus 2.4 TDCi JXFA; JXFC 85 kW / 115 PS 2006–2014
    Ford Transit Bus 2.4 TDCi H9FD 103 kW / 140 PS 2006–2014
    Ford Transit Bus 2.4 TDCi PHFA; PHFC 74 kW / 100 PS 2006–2014
    Ford Transit Bus 4x4 2.4 TDCi H9FB 103 kW / 140 PS 2006–2014
    Ford Transit Bus 3.2 TDCi SAFB; SAFA 147 kW / 200 PS 2008–2014
    Ford Transit Van 2.4 TDCi H9FA 101 kW / 137 PS 2004–2006
    Ford Transit Van RWD 2.4 TDCi JXFA; JXFC 85 kW / 115 PS 2006–2014
    Ford Transit Van RWD 2.4 TDCi H9FB; H9FD 103 kW / 140 PS 2006–2014
    Ford Transit Van RWD 2.4 TDCi PHFA; PHFC 74 kW / 100 PS 2006–2014
    Ford Transit Van 4x4 2.4 TDCi H9FB 103 kW / 140 PS 2006–2014
    Ford Transit Van RWD 3.2 TDCi SAFB; SAFA 147 kW / 200 PS 2007–2014
    Ford Transit Chassis 2.4 TDCi H9FA 101 kW / 137 PS 2004–2006
    Ford Transit Chassis RWD 2.4 TDCi PHFA; PHFC 74 kW / 100 PS 2006–2014
    Ford Transit Chassis RWD 2.4 TDCi JXFA; JXFC 85 kW / 115 PS 2006–2014
    Ford Transit Chassis RWD 2.4 TDCi H9FB; H9FD 103 kW / 140 PS 2006–2014
    Ford Transit Chassis 4x4 2.4 TDCi H9FB 103 kW / 140 PS 2006–2014
    Ford Transit Chassis RWD 3.2 TDCi SAFB; SAFA 147 kW / 200 PS 2007–2014
    Land Rover Defender (L316) — — —
    Mazda BT-50 (UP/UR) 2.2 MZ-CD 4WD P4-AT 92 kW / 125 PS 2012–

    Fitment Notes

    • Always match OEM reference number(s) and vehicle details before ordering. Confirm exact fitment using VIN, engine code, or chassis number if multiple variants exist.
    • Ford Ranger (TKE) applications cover 2.0 EcoBlue, 2.2 TDCi, and 3.2 TDCi engine variants from 2011 onward.
    • Ford Transit applications cover Bus, Van, and Platform/Chassis body types with 2.4 TDCi and 3.2 TDCi engines (2004–2014).
    • Land Rover Defender (L316) fitment covers Cabrio, Station Wagon, Pick Up, and Platform/Chassis variants.

    Installation / Use / Maintenance Tips

    • The concentric slave cylinder is located inside the bell housing — gearbox removal is required for replacement.
    • Bleed the clutch hydraulic system thoroughly after installation to remove all air from the line.
    • Inspect the clutch disc, pressure plate, and release bearing at the same time — replacing during gearbox-out service avoids repeat labour.
    • Use only the recommended clutch fluid type specified in the vehicle workshop manual.

    Common Questions

    Will this concentric slave cylinder fit my Ford Ranger?
    This part (510 0235 12) is listed for the fitments shown on this page. Confirm by matching the fitment details and verifying VIN/engine/chassis information where variants exist.

    What OEM part numbers does this cross-reference?
    Cross-reference numbers are listed in the OEM Reference Numbers section above. Match at least one to your original part before ordering.

    What brand is this part?
    This listing is for LUK concentric slave cylinder.

    How do I confirm fitment if there are multiple variants?
    Use VIN, engine code, and chassis/platform details and compare them to the fitment section above. If unsure, request fitment assistance before ordering.
